Easy Gripper 3400-5T
Professional tools for handling of OTR/EM tyres up to 36.00R51
Ideal for:
Tyre Service
Open Pit Mines & Quarries
Tyre Manufacturers / Dealers
OEM / Workshops / Assembly Lines
Unique 3-point grip
Precise rotation +/-25°
35° or 90° tilt, horizontal to vertical
Tools for safe handling of tyre rings
Integrated camera system for optimal view
Prevents damage to tyres, rims & equipment
Customization on request
Save time. Improve safety.
Easy Gripper
The Easy Gripper product range is designed to help professional tyre technicians in a multitude of conditions and situations. Implementing The Easy Gripper makes tyre handling faster and safer, while preventing damages to tyres, rims and equipment.
Capability
With a gripping range of Ø1.380 - 3.400 mm (55 - 133”) and a lifting capacity of 5.000 kg (11.000 lbs) at a CoG of 650 mm (26”), the Easy Gripper 3400-5T handles large OTR/EM tyres and wheels assemblies up to 36.00R51 even as inside duals.
Use on forklifts, front loaders and telehandlers
The Easy Gripper 3400-5T with the 90° tilt module, is ideal for use on forklifts.
The Easy Gripper 3400-5T Compact without tilt or with the 35° tilt module is a good choice depending on the tilt provided by the carrier.
Standard features
Unique and safe 3-point grip
Prevents accidents.
Prevents deformation of tyres.
Prevents damages to tyres, rims and equipment.
Integrated camera system with 2 cameras
For optimal view and for precise hub and bolt alignment.
With automatic IR function in insufficient lighting conditions.
Precise rotation +/-25°
35° or 90° tilt, horizontal to vertical
LED working light
Customized attachment system
Optional accessories
Quick Shift System
Easy hook on and off.
Shift between Gripper and forks.
Easy shift of gripping pipes for various purposes
Telescopic pipes for long reach, to provide room for the tyre technicians and for dual tyre handling.
Flat top arm for limited tyre clearance.
Tools for safe handling of tyre rings
Special designed Ring Handling Tools for handling multi-piece rim parts is another exclusive feature that is only available with an Easy Gripper. With the Ring Handling Tools the tyre technicians can grip, hold, press, or place tyres, rims and rings as needed.
- a major improvement of safety and efficiency!
Customization on request
Video
Downloads
Contact us
Improve safety and efficiency
The unique 3-point grip, precise tilt and rotation, integrated camera system and special designed Ring Handling Tools all improves the safety as well as the efficiency while handling tyres and wheels.
Optimized tyre logistics
Stacks tyres both horizontal and vertically at workshops and warehouse areas. Fast and safe loading and unloading of trailers.
Mobile and on-site tyre service
Mounted on forklifts, front loaders or telehandlers all tyre service situations in all environments can be handled in the mining industry and civil construction.
OEM assembly lines
The Easy Gripper has full control of the tyres and wheels during the whole process, until it is firmly mounted on a vehicle. Proven record of reducing internal damages with up to 90%.
Technical specifications
Technical Data
Weight: Compact = 3.050 kg / 35°= 3.200 kg / 90°= 3.300 kg
Lifting capacity:
5.000 kg (11.000 lbs) at (C) from (B) 650 mm
4.000 kg (8.800 lbs) at (D) from (B) 1.300 mm
Tyre diameter: 1.380 - 3.400 mm (55 - 133”)
Standard pipes: Ø200 x 1.100 mm (8” x 43”)
Telescopic pipes: Ø220 x 1.450 -> 1.900 mm (9” x 57” -> 75”)
Attachment: Carrier specific
Technical Requirements of forklift or loader
Lifting capacity: Individual calculation
Electrical supply: 12/24 V / min 10A
Hydraulic: 1 double acting hydraulic valve
Pressure min-max: 150 - 250 bar (2.175 - 3.626 psi)
Return pressure: max. 10 bar (145 psi)
Flow: max. 75 l/min. (19,8 gal/min.)
Explanatory description
(A) CoG Gripper: 835 mm (33”)
(B) Face of Gripper: 1.030 mm (41”)
(C) CoG Load1: 1.680 mm (66”)
(D) CoG Load2: 2.205 mm (87”)
Explanatory description
(A) CoG Gripper: 1.150 mm (45”)
(B) Face of Gripper: 1.350 mm (53”)
(C) CoG Load1: 2.000 mm (79”)
(D) CoG Load2: 2.650 mm (104”)
Explanatory description
(A) CoG Gripper: 1.660 mm (65”)
(B) Face of Gripper: 1.790 mm (71”)
(C) CoG Load1: 2.440 mm (96”)
(D) CoG Load2: 3.100 mm (122”)
Supporting tools and accessories
Even though the Easy Gripper is an incredible tyre handler / tyre manipulator, it can not do the entire tyre service job on it’s own. Therefore, we offer you following high-quality tools and accessories to support other parts of the tyre service processes.
